Specifications

Dimensions

Overall length	114 Inches
Overall width	49.5 Inches
Topped Height	80.5 Inches
Untopped Height	54.5 Inches
Wheel Base	67.75 Inches
Front Wheel Track	40.75 Inches
Rear wheel Track	40 Inches
Ground Clearance	6.375 Inches

Power

Power Source	429 cc Kohler, Overhead Valve with EFI
Motor Type	429 cc Kohler, Overhead Valve with EFI
Horse Power	14.0 hp (10.3 kW) rated at 3600 RPM per SAE J1940
Batteries (qty/type)	12V Flooded Lead Acid
Key or Pedal Start	Pedal
Battery Charger	N/A
Speed Controller	N/A
Drivetrain	Motor Shaft Direct Drive
Rear Axel Ratio	12.315:1

Performance

Seating Capacity	4
Dry Weight (w/o Batteries)	838 lbs
Curb Weight	875 lbs
Vehicle Load Capacity	800 lbs
Outside Clearance Circle	19 ft 8 inch
High Speed (Level Ground)	19.2 mph

Steering Suspension

Steering	SportDrive- Self compensating double reduction helical rack & pinion
Suspension (front & rear)	Front: Independent wide track Double A-arm with hydraulic shocks Rear: Patent pending w/Track Bar and Automotive Grade Jounce Bumpers
Brakes	Self-adjusting rear wheel mechanical drum. Parking Brake- Foot actuated, 3-position
Tires & Wheels	14" Gloss Black & Machined Mercury Wheel w/ 23x10-10 Kraken tires

Body & Chassis

Frame	Rust-resistant Aluminum
Body & Finish	Injection Molded
Available Body Colors	Standard Molded-in Color: White, Black. Premium (Metallic) Sapphire Blue, Candy Apple Red
Available Seat Colors	Standard: Beige, White, Grey, Black. Premium: Light Beige, Camello, Black, Black/Grey Two-Tone, Grey

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
